TECHNICAL SPECIFICATION:
Equivalent Input Noise (EIN)
(150 Q Source lmpedance, 20 Hz to 20 kHz)
Mic in to lnsert Send out, max gain: -126 dBu
All outouts. master levels off, all channel levels off: -95 dBuAll outouts. master levels unity, one channel level unity: -80 dBuMic in to Main Out (+4 dBu output): <0.03%
Adiacent Inputs @1 kHz: -90 dB
Inputs to Outouts @1 kHz: -80 dB
Fader Off @1 kHz: -75 dB
Mute Switch / Break Swich Mute @ 1 kHz: -90dB
Mic in to Main out, max gain, 1 kHz: 70 dB
All other outputs: 120Q Unbalanced/240Q Balanced
All inputs : +22 dBu
Main Mix XLR:+28 dBu
All other outputs: +22 dBu
Mic in: 3.3 kQ
Channel Insert Retum: 10kQ
Al other inputs: z20 kQ
Phones out 25Q
Low:+15 dB @80 Hz
High: +15 dB @ 12 kHz
Low Cut Fiter: 18 dB/ctave @ 100 Hz
Number of Presets:99
Favorite Preset: 53 (drats!)
A/D/A: 24 bit, 44.1 kHz, 48 kHz,96 kHz 192 kHz
Weight: 2.0 kg
